Mercury Relay

5V Coil 8KV 100W Mercury Wetted Relay MH05-8K

Original price was: $800.00.Current price is: $700.00.

Product Feature
High Voltage Mercury Reed Relay
Excellent Lifetime Characteristics
High Carry Current
High Insulation Resistance
External magnetic and electrostatic shield

SKU: 1158808096168 Category: Tag:

Description

Mercury Wetted Relay MH05-8K

Product Attributes

TYPE DESCRIPTION
Category Mercury Wetted Relays
Mfr SHR Reed Relay
Series 1 channels 8kv
Package Bulk
Mounting Type Through Hole
Coil Parameters
Coil Voltage 5VDC
Coil Type Non Latching
Features Diode, Electrostatic Shield
Termination Style PC Pin
Must Operate Voltage 4 VDC
Must Release Voltage 0.5 VDC
Max Operating Voltage 6.5 VDC
Coil Resistance 50 Ohms
Contact Parameters
Max Contact Rating 100W
Max Switch Voltage 8000VAC Peak/VDC
Max Switch Current 5A
Max Carrying Current 10A
Min Breakdown Voltage 8K VDC
Max Contact Resistance 100 mohm
Relay Parameters
Operating Temperature -20°C ~ 70°C
Storage Temperature -35°C ~ 105°C
Min Breakdown Voltage 8K VDC
Dielectric Strength coil/contact 8K VDC
Capacitance Across Contacts 1pF
Soldering Temperature 5sec max 260℃

wetted relay

Additional information

Weight 1 kg
Dimensions 15 × 15 × 15 cm
