5V Coil 8KV Mercury Wetted Relay HGSR05-1A08-150

Product Feature
High Power Mercury Reed Relay, Dielectric Strength up to 8000VDC
High Carry Current up to 100A(Pulse Carry Current)
Low Contact Resistance
Excellent Lifetime Characteristics
High Insulation Resistance up to 10e10
Custom design avaiable for lay out

Description

Mercury Wetted Relay HGSR05-1A08-150

Product Attributes

TYPE	DESCRIPTION
Category	Mercury Wetted Relays
Mfr	SHR Reed Relay
Series	1 channels 3kv
Package	Bulk
Mounting Type	Through Hole
Coil Parameters
Coil Voltage	5VDC
Coil Type	Non Latching
Features	Diode, Electrostatic Shield
Termination Style	PC Pin
Must Operate Voltage	4 VDC
Must Release Voltage	0.5 VDC
Max Operating Voltage	7 VDC
Coil Resistance	1.6 kOhms
Contact Parameters
Max Contact Rating	250W
Max Switch Voltage	8000VAC Peak/VDC
Max Switch Current	2A
Max Carrying Current	3A
Min Breakdown Voltage	8K VDC
Max Contact Resistance	50 mohm
Relay Parameters
Operating Temperature	-20°C ~ 70°C
Storage Temperature	-35°C ~ 105°C
Min Breakdown Voltage	8K VDC
Dielectric Strength coil/contact	3K VDC
Operate Time	2 ms
Reset Time	1.5 ms
Capacitance Across Contacts	0.3pF
Soldering Temperature	5sec max 260℃
